NP11-BNCStandard Series Parabolic Antenna 11.7 GHz

Features
Specifications
Tech Resources

Downloadable Resources

Quote
Contact Us

The Np11 Standard Series by NetPoint offers a cost effective, 10.1-11.7 Ghz, up to 68.35 miles (110km), 3ft parabolic antenna engineered to deliver reliable radio links with a stable 38 dBi gain from 10.1 to 11.7 Ghz.

Overview

Overview

Applications

Features
  • Gain of up to 38 dBi with low VSWR and high port isolation across the entire 10.1-11.7 GHz band
  • One antenna that covers 10 and 11 Ghz
  • Reduced interference with 38 dB minimum front to back
  • Simplifies installation on site and guarantees "factory-tested" quality
  • Direct waveguide
  • Various Point to Point Communication
  • Satellite Communication
  • Wirelass WAN/LAN Links
  • Radar Communication
Specifications
Frequency

10.1 - 11.7 GHz
Gain (dBi)

37: 10.1 GHz

37.5: 11.2 GHz

38: 11.7 GHz
VSWR HPOL <2.0
Polarization Vertical - Horizontal
Beamwidth

VPOL: >2.0°

HPOL: <2.0°
Wind max survival speed (MPH)

74.56 MPH with Radome
Elevation adjustment (°) +/- 20°
