Model 907

Model 907 | Radiation Survey MeterAlpha, Beta, Gamma, & X-Ray

The palmRAD 907 nuclear radiation monitoring meter provides multiple monitoring and surveying options in an easy-to-use handheld device. It measures alpha, beta, gamma, and x-ray radiation which can be displayed in rates and total counts. The user can switch between mR/hr, µSv/hr, cpm, cps, and total counts.

This model will function excellently for nearly any application. Whether the duty is radioactive food and water monitoring,or contaminated soil and water detection, the Berkeley Nucleonics PalmRAD 907 can provide the robust functionality, yet simplicity, you need to provide accurate and reliable radiological data each and every time.

There is a digital display of the selected mode and three other types of indicators - a LED indicator, an audio alarm, and an audio chirp. The LED flashes with each count. The palmRAD 907 has a user adjustable alarm threshold. When the selected level has been exceeded the powerful audio alarm will sound. The audio chirp, when enabled, emits a single chirp with each count detected. With Berkeley Nucleonics, you can have low cost, reliable, and proven nuclear radiation contamination detection in the palm of your hand.

Overview

Overview

Quick Specs

Applications

  • Detector Type: Halogen-quenched Geiger-Muller
  • Detection type: Alpha, Beta, Gamma, X-Ray
  • Weight: 350 grams (12.5 oz) with battery
  • Size: 150 x 80 x 30 mm (5.9"; x 3.2"; x 1.2")
  • Homeland Security
  • Emergency Responder
  • Safeguard and Nuclear Security
  • Radiological Area Mapping
  • Geological Radiation Survey

Radiation Monitor Features
  • Low Cost
  • Easy to Use Alarm for Emergency Responders
  • Long Calibration Interval
  • Rugged enclosure (Stainless Steel)
  • Immune to Radio Frequency Interface
  • Audio & Visual Alarm
Applications
  • First Responders
  • Emergency Service
  • HAZMAT & Local Support
  • Compliance Verification
  • Dirty Bomb Screening
  • EMT's
Specifications
Detector Halogen-quenched Geiger-Mueller tube. Effective diameter 1.75" (45 mm). Mica window density 1.5-2.0 mg/cm
Display 4-digit liquid crystal display with mode indicators
Averaging Periods Display updates every 3 seconds, showing the average for the past 30-second time period at normal levels. The averaging period decreases as the radiation level increases. User can select fast 3-second averaging period.
Operating Range mR/hr: .001 to 100.0; CPM: 0 to 300,000; Total: 1 to 9,999,000 counts; µSv/hr: .01 to 1,000; CPS: 0 to 5,000
Efficiency Sr-90 (546KeV, 2.3MeV max): approx. 75%; C-14 (156KeV max): approx. 11%; Bi-210 (1.2 MeV max): approx. 64%; Am-241 (5.5 MeV ): approx. 36%
Sensitivity 3500 CPM/mR/hr referenced to Cs-137
Accuracy ± 15%
Timer Can set 1-10 minute sampling periods in 1-minute increments, 10-50 minute sampling periods in 10-minute increments, and 1-24 hour sampling periods in 1-hour increments
Count Light Red LED flashes with each radiation event
Audio Beeper beeps with each radiation event; can be muted
Outputs Dual miniature jack drives CMOS or TTL devices, sending counts to computer or data logger. Submini jack allows for electronic calibration.
Anti-Saturation Readout holds at full scale in fields up to 100 times the maximum reading
Temperature Range -10° to +50° C , 14° to 122° F
Power One 9-volt alkaline battery; battery life is minimum 200 hours at normal background, minimum 24 hours at 1 mR/hr
Size 150 x 80 x 30 mm (5.9"; x 3.2"; x 1.2")
Weight 350 grams (12.5 oz) with battery
Options P/N6947 Cable palmRAD-to-PC P/N6954 Wipetest Plate P/N7010-1 Water Resistant Kit P/N8000-SA3-907 3yr Service Agreement for 907

Shipping Weight 12 x 9 x 4"
Shipping Dimensions 3 lbs
Technical resources
Frequently Asked Questions (FAQ)

Do you have a device that detects alpha, beta, gamma and x-ray radiation?

Do you have a device that detects alpha, beta, gamma and x-ray radiation?

The Model 907 measures alpha, beta, and gamma radiation. The device is a health and safety instrument that is optimized to detect low levels of radiation.

What Types of Radiation Are There?

What Types of Radiation Are There?

Alpha radiation, beta radiation, gamma radiation, and x radiation. Neutron radiation is also encountered in nuclear power plants and high-altitude flight and emitted from some industrial radioactive sources.
